Clough-Brengle

~ Clough-Brengle ~

Model 4581 Transmitter

in the collection at Radio Heaven

Civilian Conservation Corps

Radio Station  WUCC.

Note C-B model 4581 transmitter. This is the only photo I have ever found which proves that the model 4581 was used in C.C.C. camp stations.

C-B model 4581

Clough-Brengle

model 4581 schematic.

This schematic was redrawn by the author from the original that's mounted inside the top cover of the transmitter.

Click here to view a larger version of the 4581 schematic

"Click" on the photo to learn more about the history of this transmitter.
